Cathode - Single Crystal LiNiCoMnO2 (Ni:Co:Mn=5:2:3) NCM523 Lithium Nickel Manganese Cobalt Oxide powder

Cathode – Single Crystal LiNiCoMnO2 (Ni:Co:Mn=5:2:3) NCM523 Lithium Nickel Manganese Cobalt Oxide powder

Price range: $259.00 through $489.00

Quantity
Pay by Credit Cards

LiNiCoMnO2 (Lithium Nickel Manganese Cobalt Oxide) powder for Li-ion power battery cathode  (Ni:Co:Mn=5:2:3)

Appearance: Dark brown powder, atmospheric stability

Physical index

Item Unit Standard Reference Test method
D10 um ≥1.6 1.89 PE/Avio 500 Inductive Coupled Plasma Emission Spectrometer
D50 um 4.00±0.70 3.75
D90 um ≤10.00 6.86
D99 um ≤15.00 9.74
H2O % ≤0.035 0.019 Moisture meter
pH – ≤11.70 11.5 PH meter
Specific Surface Area (ssa) m2/g 0.78±0.15 0.78 BET meter
Tap Density g/cm3 ≥2.0 2.39 ZS-203 Tap density
3000times/amplitude3mm
Echem. Property Capacity
(mAh/g)		 ≥178.0 183.9 0.1C, 4.35～2.8V,
Coin cell test
Initial efficiency
(%)		 ≥87.0 88.5

Chemical index

Project Unit Standard Reference The analytical methods
Li % 7.30±0.50 7.35 ICP
Ni % 36.2±1.20 35.97 ICP
Co % 6.00±0.60 6 ICP
Mn % 17.00±0.90 16.92 ICP
Mg % ≤0.0300 0.0073 ICP
Cu % ≤0.0015 0 ICP
Fe % ≤0.0030 0.0007 ICP
Na % ≤0.0300 0.009 ICP
S % ≤0.1500 0.083 ICP
MI (Fe+Ni+Cr+Zn) bbp ≤50 15





Weight

500g, 1000g
